Smart-PRO Electronic Trace Heating Temperature Controller
The SOLCO PYROELEC Smart-PRO is an electronic temperature controller designed for freeze protection and temperature maintenance applications in non-hazardous locations.
Smart-PRO is designed for higher-specification trace heating applications and combines an accurate 4-wire PT100 temperature sensor, continuous fault monitoring, off-site programming capability and a wide temperature-setting range.
The controller has a maximum load current of 32A and a manufacturer-specified temperature setting range from -50°C to +499°C.
When to Choose Smart-PRO
Smart-PRO is intended for non-hazardous trace heating systems requiring a higher level of temperature range, monitoring and communications capability than a basic ON/OFF thermostat.
Freeze Protection
SOLCO PYROELEC specifies Smart-PRO for freeze-protection applications requiring electronic temperature control and continuous circuit monitoring.
Temperature Maintenance
Designed for temperature-maintenance applications with a manufacturer-specified setting range from -50°C to +499°C.
Higher-Specification Systems
Solco identifies applications including water-services plant owners, building specification engineers and industrial plants as examples of users requiring the Smart-PRO's higher level of control functionality.
Smart-PRO Key Features
Manufacturer-specified maximum load current of 32A.
Uses an accurate 4-wire PT100 temperature sensor.
Programmable setting range from -50°C to +499°C.
Actively monitors the heating circuit continuously, 24 hours a day and 365 days a year.
Built-in soft-start is designed to eliminate inrush currents and allow increased circuit lengths compared with a standard controller.
Smart-PRO includes manufacturer-specified off-site programming capability.
TTL-RS232 communications port, which Solco states can be converted to most commonly used communications protocols.
Designed to work easily with SOLCO PYROELEC heating cable termination kits.
How Smart-PRO Works
Measure Temperature
A 4-wire PT100 sensor provides temperature measurement for the controller.
Control the Heating
Smart-PRO provides ON/OFF control of the trace heating circuit according to its programmed temperature settings.
Monitor the Circuit
The heating circuit is actively monitored continuously. If a heater fault is detected, Smart-PRO generates an alarm.
Apply the Programmed Response
The heating circuit can be programmed to remain switched OFF following the relevant condition, which is the default setting, or to remain switched ON permanently.
Programming, Monitoring & Communications
Smart-PRO adds programming and communications functionality for applications requiring more than straightforward temperature switching.
The manufacturer specifies off-site programming capability, allowing Smart-PRO configuration to be prepared away from the installed controller.
Smart-PRO incorporates a TTL-RS232 communications port for controller communication.
SOLCO PYROELEC states that the communications port can be converted to most commonly used communications protocols.
Continuous Heating Circuit Monitoring
Smart-PRO actively monitors the connected heating circuit continuously throughout the year.
The heating circuit is actively monitored 24 hours a day, 365 days a year.
If Smart-PRO detects a fault in the heater, the controller generates an alarm alert.
The heating circuit can be programmed to stay switched OFF or switched ON permanently, depending on the configured controller requirement.
Smart-PRO Technical Specification
The following technical information is based on the current SOLCO PYROELEC Smart-PRO manufacturer specification.
| Product Type | Electronic temperature controller |
|---|---|
| Applications | Freeze protection and temperature maintenance |
| Location | Non-hazardous locations |
| Control Method | ON/OFF |
| Rated Voltage | 100Vac minimum – 270Vac maximum, 50/60Hz |
| Maximum Load Current | 32A |
| Temperature Setting Range | -50°C to +499°C |
| Ambient Temperature | -20°C to +60°C |
| Temperature Sensor Type | 4-wire PT100 |
| Communications | TTL-RS232 communications port |
| Enclosure Base | ABS |
| Enclosure Lid | Polycarbonate transparent lid |
| Enclosure Dimensions | 170mm × 228mm × 110mm |
| Terminals | 12 × 2.5mm² and 9 × 4mm² |
| Soft-Start | Yes |
| Fault Monitoring | Continuous, 24 hours / 365 days |
| Mounting | Direct wall mounting or pipe mounting using a SOLCO PYROELEC mounting bracket |
Smart-PRO Mounting Options
SOLCO PYROELEC supplies Smart-PRO with four plastic bracket clips to provide flexible mounting options.
Wall Mounting
The supplied plastic bracket clips allow the controller to be mounted directly to a wall.
Pipe Mounting
Smart-PRO can alternatively be mounted on a pipe using a suitable bracket supplied by SOLCO PYROELEC.
Non-Hazardous Locations
Smart-PRO is specified by the manufacturer for use in non-hazardous locations.
Complete Your Trace Heating Installation
Smart-PRO provides the temperature-control and monitoring element of the system. The complete installation will also require the correctly selected heating cable, termination components, fixing accessories and appropriate insulation.
Heating Cable
Browse trace heating cables for different frost-protection and temperature-maintenance requirements.
Shop Trace Heating Cables →Connections & Terminations
Smart-PRO is designed to work with SOLCO PYROELEC heating cable termination kits.
Shop Accessories →Fixing Accessories
Browse trace heating fixing tape, aluminium foil tape and related installation components.
View Fixings →Pipe Insulation
Complete the pipework system with insulation appropriate to the operating temperature and installation requirements.
Shop Pipe Insulation →Related Controllers & Products
Compare Smart-PRO with other SOLCO PYROELEC controllers or continue building your trace heating system.
Smart-ECO
Electronic air or surface-sensing thermostat with 20A control and fault feedback for SOLCO PYROELEC trace heating cables.
View Smart-ECO →
Smart-GUARD
Dual-circuit controller with continuous monitoring and automatic duty-to-standby switchover.
View Smart-GUARD →
Controllers & Thermostats
Compare electronic and mechanical trace heating controls for different system requirements.
View All Controllers →Not Sure Which Trace Heating Controller You Need?
Controller selection depends on the heating cable, circuit load, required temperature range, sensing requirements, monitoring requirements and communications needs.
Send the Insulation & More team your application details and we can help identify the most appropriate controller and related trace heating products.
Frequently Asked Questions
What is Smart-PRO used for?
SOLCO PYROELEC specifies Smart-PRO for freeze-protection and temperature-maintenance trace heating applications in non-hazardous locations.
What is the Smart-PRO temperature setting range?
The manufacturer specifies a temperature setting range from -50°C to +499°C.
What is the maximum load current?
Smart-PRO has a manufacturer-specified maximum load current of 32A.
What temperature sensor does Smart-PRO use?
Smart-PRO uses a 4-wire PT100 temperature sensor.
Does Smart-PRO continuously monitor the heating circuit?
Yes. SOLCO PYROELEC states that Smart-PRO actively monitors the heating circuit continuously, 24 hours a day and 365 days a year.
What happens when Smart-PRO detects a heater fault?
The manufacturer states that Smart-PRO generates an alarm alert when a fault is detected in the heater. The heating circuit can be programmed to stay switched OFF, which is the default setting, or to stay switched ON permanently.
Does Smart-PRO have a soft-start function?
Yes. SOLCO PYROELEC states that Smart-PRO incorporates a soft-start feature that eliminates inrush currents, allowing increased circuit lengths compared with a standard controller.
Does Smart-PRO support communications?
Yes. The manufacturer specifies a TTL-RS232 communications port and states that it can be converted to most commonly used communications protocols.
Can Smart-PRO be programmed off site?
Yes. Off-site programming capability is specifically listed as a Smart-PRO feature by SOLCO PYROELEC.
Can Smart-PRO be mounted on a wall or pipe?
Yes. Smart-PRO is supplied with four plastic bracket clips for direct wall mounting. SOLCO PYROELEC also states that it can be pipe mounted using a bracket supplied by the manufacturer.
Can Smart-PRO be used in hazardous areas?
No. The manufacturer specifies Smart-PRO for use in non-hazardous locations.
